The Kahles K540i 5-40x56i Riflescope sets new performance standards with its groundbreaking optical design. This innovative scope offers a 40% wider field of view, an exceptionally comfortable eyebox, and an 8x zoom with perfect optical performance across the entire adjustment range, making it one of the top scopes for long-range shooting.

First Focal Plane

With the first focal plane design, the reticle size changes as magnification is adjusted. This ensures that bar spacing and coverage remain consistent, allowing for accurate holdovers and windage adjustments at any magnification level.

Main Tube and Adjustment Features

The K540i features a robust 36 mm main tube for increased durability and enhanced adjustment capabilities. Elevation and windage adjustments can be made in either a clockwise (CW) or counter-clockwise (CCW) direction, depending on the model. The MIL click adjustment system operates in MRAD, with 0.1 MRAD corresponding to a shift of 1 cm at 100 m.

Ergonomic Design

The unique arrangement of operating elements allows for superior handling and ergonomics. All controls are easily accessible, ensuring that you can operate them comfortably without shifting your shooting position. The parallax wheel is integrated into the elevation turret, providing seamless adjustments from 20 m to infinity.

Both right-handed and left-handed shooters benefit from the patented central arrangement on top of the riflescope, making operation comfortable for everyone. The windage adjustment is ergonomically placed for easy access.

Zero Stop Functionality

The Zero Stop feature is designed to be activated after zeroing the scope. It provides a mechanical stopping point just below the zero indicator, allowing for quick and intuitive returns to zero, especially useful in poor lighting or challenging conditions.

TWIST GUARD Windage

The innovative TWIST GUARD windage system features a freely rotating end cover that prevents accidental movement of the windage adjustment. This allows for quick, unhindered handling without the need for cumbersome locking mechanisms.

Key Features

• Revolutionary Optical Design: Offers a 40% wider field of view.
• 8x Zoom: Ensures perfect optical performance across the adjustment range.
• Exceptional Eyebox: Provides comfortable eye relief, even at 40X magnification.
• Windage Adjustment: Available left or right with TWIST GUARD rotation protection.
• Integrated Parallax Adjustment: From 20 m to infinity for precise targeting.
• Reliable Clicks: 160 clicks per rotation ensure absolute repeat accuracy.
• Illuminated Reticle: Available in the first focal plane for enhanced visibility.
